INSTALLATION INSTRUCTIONS
STEP 6:
a. Place the Shade over the Socket. Using the Socket
Collar Tool, thread the Socket Collar onto the Socket to
secure the Shade. Hand-tighten until snug.
STEP 8:
a. Rotate the Shade to your desired directions.
4 OF 4
STYLE NUMBER: KY1404IB
Socket
Shade
Socket Collar
Socket Collar Tool
STEP 7:
a. Install correct bulbs referring to fixture markings and/or labels for maximum wattage.
Rotate
Your installation is completed now. Restore electricity. Retain this sheet for future reference.
