INSTALLATION INSTRUCTIONS
5 OF 5
STEP 10:
a. Place the Shade and the Steel Collar over the Socket.
Secure by threading the Socket Collar onto the Socket.
Hand-tighten until snug.
STYLE NUMBER: TY628AN, TY628WT
Steel Collar
Shade
Socket
STEP 11:
a. Install correct bulbs referring to fixture markings and/or labels for maximum wattage.
Your installation is completed now. Restore electricity. Retain this sheet for future reference.
STEP 9:
a. Pass the Ceiling Canopy over the end of the Nipple and
secure with the Big Lock Ball. Hand-tighten until snug.
Nipple
Ceiling Canopy
Big Lock Ball
Socket Collar
