Page 2
2 OF 5
STYLE NUMBER: TY628AN, TY628WT
INSTALLATION INSTRUCTIONS
STEP 1:
a. Place the Medium Assembly over the Bolts on the
Socket Assembly. Secure by threading Small Lock
Balls onto the Bolts. Hand-tighten until snug.
STEP 2:
a. Take apart the Swivel from the Ceiling Canopy by
unscrewing the Hex Nuts and the Lock Washers.
Medium
Assembly
Bolt
Small
Lock Ball
Ceiling
Canopy
Hex Nut
Socket Assembly
Lock Washer
Ceiling
Canopy
Swivel
