Quoizel TFLU433K Luxe User Manual
Page 2
TFLU433K
PART NUMBER
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2
"
REPLACEMENT PART DESCRIPTION
REQ.
NO.
2of5
FINISH: MYSTIC BLACK
GND
2.4mm
13Ga
QUOIZEL
R
6”
12”
57.5”
OVERALL HEIGHT INCLUDES
(4) 6” RODS AND (6) 12” RODS
(4)100W A19
Medium Base Bulbs
(Not Supplied)
8.5"
1"
20.5"
5"
8.5"
32.5"
1
2
3
1433KTFLU
9012EXK
9006EXK
BASE MYSTIC BLACK TFLU433K
ROD EXT MYSTIC BLACK 12"L X 0.5"D
ROD EXT MYSTIC BLACK 6"L X 0.5"D
1
6
4
4
G2986SH
SHADE TIFFANY BODY 32.5"L
1
1
4
3
2
