Step 8, Installation instructions – Quoizel ER1814IS Emery User Manual
Page 4
4 OF 4
Harp
Big Flat Washer
Small Flat Washer
Rubber Washer
Diffuser
Finial
STEP 8
:
a Thread the Hex Nut (1/8IP) onto the nipple on the bottom
end of the Harp and adjust to proper location for rest
components.
b. Place Big Flat Washer, Rubber Washer, Diffuser and Small
Flat Washer over the end of the Harp as shown. Secure
them by threading the Finial onto the nipple on the bottom
end of the Harp. Hand tighten until snug.
.
INSTALLATION INSTRUCTIONS
STYLE NUMBER ER1814IS ER1814PN
:
,
Hex Nut (1/8IP)
Your installation is completed now. Restore electricity. Retain this sheet for future reference.
