Technical Information
COLORado™ 1-Tri IP User Manual Rev. 01c -23-
Technical Specifications
Dimensions and Weight Length Width Height Weight
9.6 in (245 mm) 8.0 in (205 mm) 9.6 in (245 mm) 10.6 lbs (4.8 kg)
Note: Dimensions in inches rounded to the nearest decimal digit.
Power Power Supply Type Range Voltage Selection
Switching (internal) 100~240 V, 50/60 Hz Auto-ranging
Parameter 120 V, 60 Hz 230 V, 50 Hz
Consumption 88 W (0.7 A) 88 W (0.4 A)
Inrush current 0.4 A 0.4 A
Power Linking 12 units 24 units
Power I/O Input Output
Connectors In-line proprietary IP66 In-line proprietary IP66
Cord plug (US) Proprietary IP66 to Edison Proprietary IP66
Light Source Type Power Lifespan
LED 3 W 50,000 hours
Color Quantity Current
Tri-color (RGB) 14 1,050 mA per die
Photo Optic Parameter Standard 16º Optics
Illuminance @ 5 m 306 lx
Beam angle 17º
Field angle 32º
Thermal Maximum External Temp. Cooling System
104° F (40° C) Convection
DMX I/O Connectors Connector Type Channel Range
3-pin XLR (IP66 adapter) In-line 3, 4, 5, and 10
Ordering COLORado™ 1-Tri IP Power extension cable Signal extension cable
COLORADO1TRIIP IP5POWER IP5SIG
