Operation
COLORado™ 1-Tri IP User Manual Rev. 01c -13-
TOUR Notes These notes intent to clarify the way the TOUR DMX personality works.
Master Dimmer · Channel 1 controls the intensity of the currently projected color.
· When the slider is at the highest position (255) the intensity of the output is at its
maximum.
Red, Green, & Blue
Color Selection
· Channels 2, 3, and 4 control the intensity ratio of each of the Red, Green, and Blue
LEDs.
· When the slider is at the highest position (255), the intensity of each color is at its
maximum.
· You can combine channels 2, 3, and 4 to create over 16 million colors.
Color Macros · Channel 5 selects the required Color Macro.
· Channel 5 has priority over channels 2, 3, and 4.
· Channel 1 controls the intensity of the Color Macro.
Strobe · Channel 6 controls the strobe frequency (not the intensity) of channels 2~5.
· Channel 6 strobes channels 2, 3, and 4 when not running macros, allowing the
individual faders (R, G, and B) as well as channel 1 (D) to control the output
intensity.
· Channel strobes channel 6 when running macros, allowing channel 6 to select the
macro and channel 1 to control the output intensity.
Auto · Channel 7 selects the preset auto programs AT. 01~10 or the custom programs
CUS. 01~10.
· When activating the custom programs CUS. 01~10, it is possible to control the Step
Time and Fade Time using channels 2 and 3 respectively.
· Channel 7 has priority over channels 2, 3, 4, 5, and 6.
Dimmer Speed · Channel 9 is for selecting the dimmer mode and speed. When Dimmer is set to Off,
the Red, Green, Blue, and Dimmer outputs are linear with the faders. Otherwise,
Dim1 is the fastest dimmer curve, while Dim4 is the slowest.
ID Address
Selection
· Channel 10 selects the target ID address.
· Each independent DMX address may have up to 66 independent ID addresses.
· An ID address of 0 will activate all ID address locations.
