Quoizel UPPS2813BN Uptown Penn Station - Manual (Page 2)

UPPS2813BN
1
2
PART NUMBER
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2 "
REPLACEMENT PART DESCRIPTION REQ. NO.
2of7
6”
12”
FINISH: BRUSHED NICKEL
3
GND
2.4mm 13Ga
QUOIZEL
R
(3)T8 Candelabra
Filament 40W Bulbs
(Supplied)
1"
6.5" Dia.
66”
OVERALL HEIGHT INCLUDES
(2) 6” AND 12” RODS
23.5”
14”
11.5" Dia.
13.5" Dia.
4 I1103CC
9008EXBN01
9007EXBN01
G3621SH
T8-60W TUBULAR FILAMENT CANDELABRA BULB
ROD EXTENSION BRUSHED NICKEL 12"L X 0.63"D
ROD EXTENSION BRUSHED NICKEL 6"L X 0.63"D
GLASS CLEAR 11.5" D
3
2
2
1
3
2
1
4
