Quoizel TRG5103OZ Trilogy User Manual
Page 2
TRG5103OZ
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2"
NO.
2
1
2of7
FINISH: OLD BRONZE
5” Dia.
1”
Overall Height 70”
(Includes 48” Chain)
20”
5”
8” Dia.
26” Dia.
PART NUMBER
M2374CHOZ
G3642SH
REPLACEMENT PART DESCRIPTION
CHAIN OLD BRONZE 3.8MM x4’
GLASS CLEAR SEEDY 8"D
REQ.
1
3
(3) Medium Base
Decorative Filament
60W bulb (suppled)
Maximum 100W
NOTE: TWO LIGHTS SHOWN FOR
ILLUSTRATION PURPOSES ONLY.
GN D
2.4mm
13Ga
QU O IZEL
R
1
2
