Quoizel MY2816ML Monterey Mosaic User Manual
Page 2
MY2816ML
FINISH: MALAGA FINISH
5
6
4
PART NUMBER
MTG HDWR MALAGA 5.25”D
9123KIT
G2043SH
M1843FIML
1
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2
"
REPLACEMENT PART DESCRIPTION
REQ.
NO.
SHADE PEN SHELL MOSAIC 18.5”
FINIAL MALAGA .79”HX.71”D
1
1
2of8
Dia. 5”
2”
22”
Overall Height 121”
(Includes 96” Chain)
Dia. 18”
3
2
1
M682CHML
M1862CAML
12816MLMY
CHAIN MALAGA 3.8MMX4’L
CAP MALAGA 4”D
BASE MALAGA FOR MY2816ML
1
1
1
1
4
2
3
5
6
(3)100W medium
base bulb
(not Supplied)
