STEP 9
:
a
Locate the Shade over the Socket. Using the Socket
Collar Tool (supplied), thread the Socket Collar onto the
Socket to secure the Shade. Hand tighten until snug.
.
Socket Collar
Shade
STEP 10
:
a
Install correct Bulbs referring to fixture markings and or labels for maximum wattage
Your installation is completed now
Restore electricity
Retain this sheet for future reference
.
/
.
.
.
.
Socket
INSTALLATION INSTRUCTIONS
Socket Collar
Tool
5 OF 5
STYLE NUMBER DH5009AN, DH5009PN
:
