Quoizel ALZ5005PN Aliza - Manual (Page 3)

ALZ5005PN
PART NUMBER
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2 "
REPLACEMENT PART DESCRIPTION REQ. NO.
(5)
Bulbs
(Not Supplied)
Medium Base
23W CFL
1
GND
2.4mm
13Ga
QUOIZEL R
FINISH: PALLADIAN BRONZE
2
3
15005PNALZ
M381CHPN
8822KIT
BASE PLLDN BRNZ ALZ5005PN
CHAIN PALLADIAN BRNZ 3.8MMX4’
KIT CANOPY PALLA BRNZ REPL
1
1
1
NOTE: TWO LIGHTS SHOWN FOR
ILLUSTRATION PURPOSES ONLY.
Overall Height 74”
(Includes 48” Chain)
6.5" Dia.
5.5"
23"
28" Dia.
6.5" Dia.
1.5"
2
4
4 G2970SH SHADE GRADIENT AMBER MIST GLS 5
1
3
3of3
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2013 QuoizelInc. December2013
