Mesur-Fil Fluid Couplings
158 Wichita Clutch 800-964-3262 P-1100-WC 1/12
* Modular design (See page 167)
Mounting
Type
Parallel, QD sheave application
For use with flexible gear couplings
Basic coupling for custom input & output
Shaft to shaft applications
For stub shaft input/output sizes 7-12.4
Mounting
Ap pli ca tion
HBM
(page 169)
HSD
(pages 172-173)
HCM
(pages 170-171)
HC
(page 168)
Mounting Types per Size
Size
7.0* 9.4* 12.4* 15 17 19 21 24 27 29 34
• • •
• • • • • • • • • • •
• • •
• • • • • • • •
