Mesur-Fil Fluid Couplings
168 Wichita Clutch 800-964-3262 P-1100-WC 1/12
Size L M N O R S U V W X Y Z
7.0 4.17 1.50 1.270 1.91 .60 .750 1.10 .60
9.4 5.42 1.50 1.905 2.90 .83 1.062 .96 .80
12.4 6.75 1.80 2.05 3.156 .90 1.125 .96 .90
Model HC (Custom Applications)
Sizes 7.0 – 12.4
9/64
x
.26
13/64
x
.50
13/64
x
.50
Output Shaft
(Detail drawing)
.9845 1.124 1.250
.9839 1.116 1.249
1.3782 1.577 1.850
1.3776 1.589 1.749
1.5746 1.785 2.000
1.5750 1.777 1.994
Dimensions: inches
Dimensions: inches
Oil
Wt. Lb. US Oz.
Size A B C D E F Less Oil Max.
7.0 7.81 3.67 .56 4.23 3.188 17/64 10.1 27.6
9.4 10.25 4.70 .77 5.47 4.250 25/64 20.5 65
12.4 13.50 5.98 .82 6.80 5.650 25/64 38.0 150
Size Assembly Number
7.0 6-607-001-002-0000
9.4 6-609-001-001-0000
12.4 6-612-001-002-0000
3/8" NPT
4-619-068-000-0
Fusible Plug
