Printer Operation
Top Menu
Sub Menu
Default
Menu
Remarks
Paper Position
0.00 inch
Peel/Cut/Tear Off
Adjusts the stop position. It is based on the
0.00 mm
0.00 to 2.00 inch
inch/millimeter setting. There are initial
0.0 to 50.8 mm
values of the stop position for each device
Peel/Cut/Tear On
set above, and later, relative values are set.
-1.00 to 1.00 inch
-25.4 to 25.4 mm
Menu Key Action
Enters Menu
Enters Menu
Sets the menu key action.
Repeat Last One
Enters Menu:
Enters the menu setup mode.
Repeat Last One:
Last one is issued only for the final page.
In the case of a count, afterwards, only
last one is issued.
Note: Hold down the MENU key for at least 4
seconds in order to enter the Menu Setup
Mode when setting the “Repeat Last One”
menu.
Interfaces
RS-232C Baud
9600
115200
Setting the baud rate of the serial interface.
57600
• All settings related to the interfaceare
38400
enabled after the power is reconnected.
19200
9600
4800
2400
RS-232C Parity
None
None
Setting the communication parity for the
Odd
serial interface.
Even
RS-232C Length
8 bits
8 bits
Setting the character length for the serial
7 bits
interface.
RS-232C Stop bit
1 bit
1 bit
Setting the stop bit for the serial interface.
[RS-232C Stopbit]
2 bits
RS-232C X-ON
On Yes
On Yes
Selectively setting the X-ON flow control of
Off No
the serial interface.
IEEE1284
On
On
Setting both direction of the Centro
Off
Interface.
Web Monitor
Auto
Auto
Selecting the web monitor function.
On
Off
Network Address
0.0.0.0
0.0.0.0 to
Setting fixed IP address of the LAN board.
255.255.255.255
Subnet Mask
0.0.0.0
0.0.0.0 to
Setting fixed subnet mask value of the LAN
255.255.255.255
board.
Gateway address
0.0.0.0
0.0.0.0 to
Setting fixed default gateway address of the
255.255.255.255
LAN board.
BOOTP
Off
On
Setting the BOOTP of the LAN board.
Off
DHCP
Off
On
Setting the DHCP of the LAN board.
Off
USB Device Class
Printer
Printer
Selects the USB device class.
[USB Device Clas]
VCOM
USB VCOM Protocol
Auto
Auto
Selects the protocol (flow control) when
[VCOM Protocol]
DTR
operating USB VCOM.
X-ON
Mode Settings
[Zebra
®
Emulation]
