24
t riGGer G roup i nstAllAtion
1. Before reinstalling the trigger group, make sure
that the bolt is fully forward and engaged in the
locked position.
2. Visually check the “safety” on the trigger guard to
make certain it is still in the on safe position.
3. Insert the trigger group back into the receiver, lining
up the holes in the trigger group with the holes on
each side of the receiver.
4. Insert the trigger group pins from either side of the
receiver and gently tap them into place using care not
to scratch the receiver.
Your firearm is now fully assembled. Immediately confirm
that the “safety” is in the on safe position. Take time to
wipe down and clean all external surfaces as explained
under “Cleaning and Maintenance Suggestions” on
page 21.
NoTICe! do not taKe your FirearM’s aCtion aPart
beyond what is exPlained in this owner’s
Manual. this is a sPeCialiZed, Finely Fitted
MeChanisM; any atteMPt to disasseMble the
inner MeChanisM May daMage it. it is
unneCessary, and May do daMage to the inner
MeChanisM to disasseMble it For routine
Cleaning and oiling. oF Course, MisFortunes
(suCh as droPPing your FirearM in water)
require aPProPriate attention, and in suCh
CirCuMstanCes we reCoMMend you iMMediately
taKe your FirearM to a qualiFied gunsMith.
m AGAzine m AintenAnce
wear eye ProteCtion when disasseMbling and
Cleaning your riFle to Prevent sPrings, sPring-
loaded Parts, solvents or other agents FroM
ContaCting your eyes, resulting in injury.
We do not recommend disassembling the magazine.
Frequently inspect magazines to determine the need for
cleaning as lubricant and dirt will gradually collect in
the mechanism.
NoTICe! do not taMPer with the asseMbly Pin on
the bottoM oF the MagaZine. doing so will
render the MagaZine inoPerative.
c leAninG the m AGAzine
1. Clean the magazine by spraying it with a gun cleaning
solvent that will not adversely affect the polymer
magazine follower or corrode the metal components.
Spray the magazine with this solvent, both inside and
out, to loosen debris.
2. Drain the solvent and residue from inside the magazine.
3. Use compressed air to dry the magazine, or allow it
to air dry, and lightly oil.
