Transmitter (Tx) Button Function Matrix!
Function Button Activation Hold Time LED Status
Power ON/OFF POWER Press and Hold 2 sec Solid Green
Pairing Mode LINK Press and Hold 3 sec Fast Green Flashes
Signal Re-routing LINK Click Click
Volume UP/Down Click for Step, Press and hold for Auto Click
Mute ON/OFF Press and Hold 1.5 sec Solid Green and Blue
Sleep / Wake up Press and Hold to Sleep / Click to Wake 2 sec Two Green Flashes
Passive Guitar Mode MODE Press and Hold 2 sec Solid Green LED and
(Factory setting) Slow Blue LED Flashes
Active Guitar Mode MODE Press and Hold 2 sec Solid Green LED and
(Mono Line-in) Fast Blue LED Flashes
Line in Mode MODE Press and Hold 2 sec Solid Green LED and
(Stereo Line-in) Two Blue LED Flashes
Tx FUNCTION MATRIX
Wi AudioLink
30
