Transmitter Controls and Connections
j
Audio IN Jack:
Provides a stereo connection for professional musical instruments and more...
k
Power ON/OFF:
Press and hold the Power button for 2 seconds to turn the transmitter ON or OFF.
l
Power/Status LED:
The Power/Status LED displays the status of six functions, ON/OFF, Battery
Charging, Low Battery, Pairing, Mute, Operations and Sleep mode.
F
Please refer to the “Tx Button Function Matrix” section of this manual for more details
m
Volume UP:
Press and hold the Volume UP to automatically increase the volume level.
Press the Volume UP once to increase the volume level one step at a time.
n
Volume DOWN:
Press and hold the Volume DOWN to automatically decrease the volume level.
Press the Volume DOWN once to decrease the volume level one step at a time.
TRANSMITTER FEATURES
