Operating instructions WHA 3000P
Front view WHA3000P
1
LCD Display
2
"UP" Control Key
3
"DOWN" Control Key
4
Mains Switch
5
"TIME"/"PREHEAT" Control Key (time setting auto. mode / pre-heating temperature)
6
"AIR" Control Key (air flow rate)
7
"TEMP" Control Key (hot air temperature)
8
LED Indicator, Vacuum
9
LED Indicator, START/STOP
10
"START/STOP" Control Key
11 "VAC" Control Key (activate Vacuum)
12 "AUTO" "MAN" Control Key (changeover Automatic Manual operating mode)
13 LED Indicators, Auto-Man operating mode
14 Connection for External Sensor Type K
