A-5
3. You will see TCP/IP -> Microsoft IrDA LAN Driver is listed in the
Network panel.
4. Once present, double click Microsoft IrDA LAN Driver in the Network
panel. Select Bindings. Insure that TCP/IP --> Microsoft IrDA LAN
Driver
is checked on. Click OK. This returns you to the Network panel.
Select TCP/IP --> Microsoft IrDA LAN Driver. Select Properties. An
IP Address needs to be assigned.
5. To assign a static IP address, click Specify an IP address, then type in the
IP address according to your corporate network policies. Click OK. The
process is complete. You can close all of the panels. The static IP address
approach allows you to assign a permanent IP address manually.
Networked environments that did not use TCP/IP before should use this
approach.
6. To assign an automatic IP address, you would instead click Obtain an IP
address automaticall y. Click OK. The process is complete. You can
close all of the panels. The automatic IP address approach allows the IP
address to be configured automatically. It minimizes administration effort
and allows reuse of the IP address. It is recommended for networks with
DHCP.
For other configurations such as DNS, Gateway, etc., please see your system
administrator.
