Triton TWS S10 - Manual (Page 5)

5
GB
e) Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and
any other condition that may affect the power
tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by
poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to
be performed. Use of the power tool for operations
different from those intended could result in a
hazardous situation.
5) Service
a) Have your power tool serviced by a qualified repair
person using only identical replacement parts.
This will ensure that the safety of the power tool is
maintained.
Safety Instructions / Unpacking / Assembly / Preparation
• Carefully unpack and inspect your tool. Familiarise
yourself with all its features and functions.
• Ensure that all parts of the tool are present and in
good condition. If any parts are missing or damaged,
have such parts replaced before attempting to use this
tool.
IMPORTANT: Remove protective packing around the
motor before assembly
1. Ensure the unit is not connected to power
2. Carefully lay the machine on its side to gain access to
the motor cavity
3. Remove protective packing in and around the motor
4. Carefully return unit to the upright position
UNPACKING
FIT THE GRINDSTONE AND WATER TROUGH
1. Place a Metal Washer (7) onto the spindle, profile
facing away from the body of the machine
2. Place the Grindstone (6) loosely onto the spindle, with
the depressed centre of the grindstone facing away
from the body of the machine (as shown in image)
3. Clip the Water Trough (5) into position. Use the
appropriate fixing position to suit the size of grindstone
to ensure stone is free to rotate yet reaches below the
max water level (as marked on trough)
4. Place the other Metal Washer (7) onto the spindle,
profile facing the grindstone
5. Fasten with the Locking Nut (8). Use spanner supplied
to secure tightly.
NOTE: This spindle has a reverse thread, turn nut anti-
clockwise to fasten
6. Rotate the grindstone by hand a few turns to ensure
that it moves freely and accurately
LEATHER HONING WHEEL
1. The unit is supplied with the Leather Honing Wheel (1)
fitted
2. Before use, check that the honing wheel is securely
fastened in place
3. Turn the Locking Knob (3) clockwise to tighten.
NOTE: Tighten by hand only.
ASSEMBLY
SITING THE UNIT
• Position the unit on a solid work surface, with all four
feet securely planted on the surface
• Ensure there is adequate light to see the work clearly
and sufficient space around the unit so that there are
no obstructions
FILLING THE WATER TROUGH
1. Fill the Water Trough (5) with cold water up to the MAX
WATER LEVEL mark on the side of the water trough
2. When in use, ensure the water level is always
sufficient to keep the grinding surface of the
Grindstone (6) wet
ENGAGING THE DRIVE SYSTEM
1. Tighten the Torque Adjustment Knob (10) by turning
it clockwise until it is tight up against the body of the
machine. This will engage the drive system
2. After use, always loosen the toque adjustment knob.
This will help to ensure the drive wheel retains its
correct shape
PREPARATION
