PRODUCT FAMILIARISATION
Product Familiarisation
1
1. Auxiliary Handle
2. Dust Extraction Port
3. Lock-On Button
4. Main Handle
5. Drive Belt Cover
6. Tracking Adjustment Knob
7. Handle Lock
8. Power ON Neon
9. On/Off Trigger Switch
10. Dust Bag
11. Front Belt Roller
12. Belt Tension Lever
4 3
6
2
7 5
11
9
13
10
14 12
8
15
16
17
18
19 20
13. Drive Roller
14. Variable Speed Control Knob
15. Inversion Clamps
16. Backstop Locking Screw
17. Backstop
18. Sanding Frame (model number TBSIS, available separately)
19. Depth Plate Locking Knob
20. Frame Locking Knobs
Included Accessories:
• 80 Grit sanding belt (pre-fitted)
• Spare drive belt (not shown)
