P20 PUMP OPERATION / MAINTENANCE MANUAL PAGE 5
Air Inlet:
3/8” OD Tubing)
Air Supply: 20-80 PSIG (0.14 - 0.55 Mpa), clean dry air or inert gas
Fluid Ports: 1/2” Flaretek standard (other options available)
For maximum flow the following is recommended:
1. Maximize supply line diameter
2. Minimize supply line length
3. Minimize supply line restrictions (i.e. valves, fittings)
NOTE: It is recommended that a filter be placed on the discharge side of the pump.
ATTENTION: The pump should be operated with clean, dry air or nitrogen. Particulate,
water and oils in the air supply can damage the pump.
