NOTE: See Surge Suppressor Operation Manual for detailed installation
instructions.
2.3 OPTIONAL LEAK SENSING
2.3.a Installation
• Remove plug and seal from port.
• Install probe assembly into leak sensor port. Probe is self-sealing and does
not require a seal.
• Thread probe cap into port. (NOTE: Do not over tighten; damage to
threads will occur.)
• Connect fiber optic cable to sensor (NOTE: Minimize bends in fiber optic
cable to 2” radius minimum to help ensure optimum signal strength.). Fiber
optic cable can be cut to desired length using the cable cutter provided.
Figure 2-3
