4.5 PARTS LIST
ILL
NO PART NO QTY DESCRIPTION PM
YEAR #
MATERIAL
1 L0154 2 Check Bore Cap PTFE
2 L0163 2 Seal, Check Port 1 PTFE
3 L0096 2 Discharge Sleeve PTFE
4 98002740 4 Check Ball 1 PTFE
5 98002261 4 O-Ring 1 PTFE
6 L0191 4 Check Seat Wear Ring PTFE
7 L0193 2 Suction Sleeve PTFE
8 L0190 1 Body PTFE
9 L0192 1 Shaft Bushing 1 PTFE
10 L0195 1 Locking Ring PTFE
11 L0123 1 Main Shaft 2 PFA
12 1900B0070 2 Push Plate PTFE
13 1900B0023 2 Diaphragm Set 1 PFA
14 98001585 2 Main Seal 1 Viton
15 L0141-01 1 Master Head PP
16 1900B0027-01 8 Tie Bolt Assembly SS316, PFA
17 L0100 16 Tie Bolt Cap 1 LDPE
18 W0114 2 Cap, Pilot PP
19 W0116 2 Seal, Pilot Cap PTFE
20 W0123 2 Assembly, Pilot Valve, Wear Resistant Peek, PTFE,
PPS, Viton
21 W0117 2 Seal, Pilot Sleeve PTFE
22 AM040 2 Leak Port Cap PP
23 L0167 2 Leak Port Seal PTFE
24 98003047 2 Quick Exhaust Seal 1 Viton
25 1900B0016 2 Quick Exhaust Port UHMW
26 L0119 2 Muffler Assembly 1 PP
27 98003080 2 Plug, Remote Exhaust PE
28 AK058 1 NM Sleeve Assembly Ceramic,
PTFE
29 L0105 1 Adapter, Detent PP
30 L0131 1 Assembly, Spool External, High Load Ceramic,
PEEK,
Torlon
30A L0197 2 Leg, Detent 1 Torlon
30B L0145 1 Ring, Detent, High Load 1 PEEK
31 L0113 1 Seal, Detent Cap PTFE
32 L0104 1 Cap, Detent External PP
33 L0139-01 1 Slave Head PP
34 L0140 8 Bushing NPRN,EPDM
35 1900A0028-01 8 Tie Bolt Washer SS316
36 98002341 8 Nut, Flange, SS, 1/4 - 20 SS18-8
37 98002620 1 Label Cap LDPE
38 98001418 4 Insert SS18-8
39 1900B0033 1 Pump Base PP
40 98001093 4 Washer SS18-8
41 98001375 4 Screw SS18-8
42 98001108 4 Cap, Blue LDPE
43 1900A0024 2 Main Transfer Tube PFA
44 98002240 2 O-Ring 1 Viton
45 1900A0025 1 Shuttle Transfer Tube PFA
46 98002303 4 O-Ring 1 Viton
47 98003755 1 Screw, Locking Ring PTFE
48 98003769 2 Screw, Push Plate PTFE
4.6 CLEAN-UP
To help remove potentially dangerous chemicals, the pump can be flushed with
DI water or disassembled and thoroughly cleaned.
MEGA 960D PUMP OPERATION / MAINTENANCE MANUAL PAGE 15
