TerraLUX TRK-R16 Product Specification (11/18/2013) Subject to change without notice 4
TESTS AND CERTIFICATIONS
Product Safety Certifications • UL Standard 1574:2008 Track Lighting Systems
Radio Frequency Emissions •FCC Part 15, Unintentional Radiators Class A.
Sec 107, Conducted Emissions - 0.15MHz – 30MHz
Sec 109, Radiated Emissions - 30 MHz – 8000MHz
•Industry Canada Notice ICES-003: Class A Digital Apparatus
Reduction of Hazardous Substances
(RoHS) • European Council Directive 2002/95/EC, (including amendments 2005/618/EC,
2005/717/EC and 2005/747/EC) on the restriction of certain hazardous substances in
electrical and electronic equipment.
Electro-Static Discharge •± 4kV and ± 6kV contact discharge
•±8kV and ± 10kV air gap discharges
Power Factor 0.92 @ 12 V AC (high mode)
Drop Test Drop from a distance of 1 meter onto a non-resilient test floor. The test surfaces shall
be the face, two opposing sides, the base, and two opposing top corners. Operation is
to be checked after each impact.
Shipping / Transit International Safe Transit Association (ISTA) Project 2A.
Operating Temperature -40°C to +45°C, 0 to 95% R.H. / 157 hr.
Storage Temperature -40°C to +85°C / 60 hr. followed by 20°C to 85°C, 5 to 95% R.H. / 80 hr.
Lumen Maintenance L70 =60,000hr per IES TM-21-11 (Based on LED Manufacturer’s measurement per IES
LM-80-08 @ 10.000hrs).
Long Term Operation (Module) MBTF = 70,000 hours (TerraLUX TLM-R16C light engine)
Input Voltage Range 108-132V AC
