TerraLUX TRK-R16 Product Specification (11/18/2013)
Subject to change without notice
2
PHOTOMETRY
Narrow: 19°
Flood: 34°
Wide Flood: 60°
Illumination at a Distance (3000K)
Relative Candela Distribution (3000K)
PERFORMANCES
Notes:
1) Typical Performance @ 25°C ambient . All specifications subject to tolerance of ± 10%
2) All information consistent with IESNA LM-79-08 testing, completed by a qualified third party facility
3) All measurement taken in Mode 1 (High), for other modes check the matrix here :
4) Dimmer should only be used in Mode 1 (High)
Color Temperature
CRI Minimum (typical)
Light Output [lm]
Power [W]
Efficiency @ 12V AC [lm/W]
Beam Angle
19°
34°
60°
19°
34°
60°
19°
34°
60°
Center Beam Candle Power [cd]
2877
1118
435
3206
1173
456
3341
1208
470
3000K and 3500K
80 [85]
640
12.5
51.2
2700K
80 [85]
610
12.5
48.8
4000K
80 [85]
650
12.5
52
Lumen Output
(3000K)
Typical Power
Consumption
Mode 1 (High) - 50W eq.
640
12.5
Mode 2 - 35W eq.
501
8.3
Mode 3 - 20W eq.
388
5.8
Mode 4 (Low)
305
4.3
Mounting Height
Diameter
In feet
FC
In feet
6
78.7
2.1
8
44.3
2.8
10
28.3
3.4
12
19.7
4.1
14
14.4
4.8
16
11.1
5.5
Mounting Height
Diameter
In feet
FC
In feet
6
11.3
10.4
8
6.3
13.9
10
4.1
17.3
12
2.8
20.8
14
2.1
24.2
16
1.6
27.7
Mounting Height
Diameter
In feet
FC
In feet
6
30.0
4.0
8
16.9
5.4
10
10.8
6.7
12
7.5
8.1
14
5.5
9.4
16
4.2
10.8
