Mounting the thermostat, If a gang box is used – tekmar 012 Adaptor Plate User Manual
Page 2
© 2013
012_D - 03/13
2 of 4
A Watts Water Technologies Company
Mounting The Thermostat
3
1
/
4
”
(83 mm)
Stud
Gang
Box
Thermostat
Front
Thermostat
Base
Adapter Plate 012
If a gang box is used:
Feed the wiring through the hole in the adaptor plate and the thermostat base.
Fasten the adaptor plate to the gang box.
Fasten the base of the thermostat to the adaptor plate.
Terminate wiring to the wiring strip.
Push the thermostat front onto the thermostat base.
•
•
•
•
•
