SWIT Electronics S-1092H User Manual
Page 8
⑹ Marker Back: Normal, Semitransparent, Black
Normal: Normally display the outer area of scale marker
Semitransparent: half-tone display the outer area of scale marker
Black: Black display the outer area of scale marker
3.4 OSD submenu
The OSD submenu includes:
⑴ Menu Position: Center, right top, right bottom, left
top, left bottom
⑵ Menu timeout: 0～60s
Set a time (in seconds) in which the menu will
automatically quit if remains idle. Default: 30.
⑶ Language: Menu language selection
⑷ Source ID Display：On/Off
⑸ Source ID Character：CAM 1。
Revolve "ENTER" button to select the letters, and press "ENTER" to input. Max 10 letters are
supported, the default is CAM1. There are 76 letters available, details are as below:
A
～Z a～z 0～9 ！
&
‘
（
） *
+
，
-
.
/
:
?
⑹ Input info Display：On/Off
On
：turn on the OSD info display
Off
：turn off the OSD info display
3.5 System submenu
The system submenu includes:
⑴ Backlight: 0～100 value adjustment
⑵～⑸ F1～F4 Button: define Function Key F1, F2, F3
and F4, function includes:
⑹ Input Source Scan: On/Off
Switch on: when turn on the monitor, it will scan the signal input with the sequence: SDI1
→SDI2→
HDMI
→CVBS until the first recognized input and automatically display.
⑺ Tally R Brightness: Low, Medium, High
⑻ Tally G Brightness: Low, Medium, High
⑼ Reset: Yes/No
Select “YES” to recover all to factory settings expect Language setting.
SD Aspect Ratio
Zebra
Scan
B/R/G Only
Zoom
Time Code
Mono
CVBS
Freeze Frame
HDMI
Button Lock
SDI1
PIP
SDI2
Focus Assist
Undefined
Audio Bar
