Handbook for the SXVR-H814C
Issue 1 February 2013
31
‘Maxim DL’ is another popular choice and you can find out more by visiting
‘Nebulosity 3’ also works very well with the H814C.
*********************************************************************
Some details of the camera and CCD characteristics
The SXVR-H814C uses a Sony ICX814AQG ‘EXview’ progressive scan CCD, with
3388 x 2712 x 3.69uM pixels in a 12.48 x 9.98mm active area. This EXview device
CCD type:
Sony ICX814AQG EXview interline imager.
CCD size:
Active area 12.48mm x 9.98mm
CCD pixels: 3388 x 2712 pixel array. Each pixel is 3.69 x 3.69uM square
Bayer Matrix: RGGB primary colour
Well depth: Full res. mode 17,000e. Binned 2x2 mode approx. 20,000e
Mean visual QE: 70%, 75% at peak (580nM)
Useful spectral response: 360nM – 1100nM
Readout noise: Approx. 4e RMS typical, 8e max.
Back focal distance: The CCD is approximately 17mm from the barrel front.
Camera size: 63mm diameter x 62mm long
