702 User Guide and Technical Information
58
v. 2.67 Features and specifications are subject to change. Visit www.sounddevices.com for the latest documentation.
702 Presets Factory Preset
Film
Preset
Reporter
Preset
Music
Preset
Mic Input 2: Low Cut
Frequency
40 Hz, 12 dB/oct 40 Hz, 12 dB/oct 40 Hz, 24 dB/oct 40 Hz, 12 dB/oct
Mic Input 1: Gain Range Normal Normal Normal Normal
Mic Input 2: Gain Range Normal Normal Normal Normal
Input 1,2: Source Auto Select Auto Select Auto Select Auto Select
Input 1,2: Linking, MS Unlinked Unlinked Unlinked Linked 1,2
Line Input 1,2: Gain Ctrl Use Front Panel Knobs Use Front Panel Knobs Use Front Panel Knobs Use Front Panel Knobs
Input 1: Delay 0 mS 0 mS 0 mS 0 mS
Input 2: Delay 0 mS 0 mS 0 mS 0 mS
File: Marker Mode New File New File New File New File
File: Max Size 2G CF (1.8 GB) 2G CF (1.8 GB) 2G CF (1.8 GB) 2G CF (1.8 GB)
File: Folder Options None None None None
File: Copy Files Copy all CF> EXHDD Copy all CF> EXHDD Copy all CF> EXHDD Copy all CF> EXHDD
File: Copy Flag Reset Enabled Enabled Enabled Enabled
Time Counter: Display Big A-Time Big A-Time Big A-Time Big A-Time
Time Counter: Mode Off Off Off Off
Output1 Left: Source Track A Track A Track A Track A
Output1 Right: Source Track B Track B Track B Track B
Output1 L,R: Attenuation 0 dB 0 dB 0 dB 0 dB
Output2 Left: Source Track A Track A Track A Track A
Output2 Right: Source Track B Track B Track B Track B
Output2 L,R: Attenuation 0 dB 0 dB 0 dB 0 dB
Digital Output: Mode Consumer Consumer Consumer Consumer
Play: AutoPlay Mode Play All Play All Play All Play All
Time/Date: 12/24 Hr 12 Hr 12 Hr 12 Hr 12 Hr
Time/Date: Date Format MM/DD/YY MM/DD/YY MM/DD/YY MM/DD/YY
LCD Contrast 50% 50% 50% 50%
LCD: Gain Display Bit Depth, SR & Gain Bit Depth, SR & Gain Bit Depth, SR & Gain Bit Depth, SR & Gain
LCD: Scrolling Direction Normal Normal Normal Normal
Meter: Ballistics Peak Hold + VU Peak Hold + VU Peak Hold + VU Peak Hold + VU
Meter: Peak Threshold 0 dBFS 0 dBFS 0 dBFS 0 dBFS
Meter: Stealth Mode Off Off Off Off
HP: Rotary Sw Function Selects Favorite Mode Selects Favorite Mode Selects Favorite Mode Selects Favorite Mode
HP: Monitor Modes
01> Inputs 1,2
02> Tracks A,B
03> Input 1,1
04> Input 2,2
05> Monitor A,B 01> Inputs 1,2
02> Tracks A,B
03> Input 1,1
04> Input 2,2
05> Monitor A,B
01> Tracks A,B
01> Inputs 1,2
02> Tracks A,B
03> Input 1,1
04> Input 2,2
05> Monitor A,B
HP: Favorite Mode Tracks A,B Tracks A,B Tracks A,B Tracks A,B
HP: Playback Mode Tracks A,B Tracks A,B Tracks A,B Tracks A,B
HP: Warning Bell -30 dBFS -30 dBFS -30 dBFS -30 dBFS
HP: Record/Stop Bell Disabled Disabled Disabled Disabled
Tone: Level -20 dBFS -20 dBFS -20 dBFS -20 dBFS
Tone: Frequency 1000 Hz 1000 Hz 1000 Hz 1000 Hz
Tone: Mode To Rec Tracks and Outputs To Rec Tracks and Outputs To Rec Tracks and Outputs To Rec Tracks and Outputs
Tone: Record Lock Locked while Recording Locked while Recording Locked while Recording Locked while Recording
CF: Empty Trash Empty Trash Empty Trash Empty Trash Empty Trash
