Back Panel Descriptions
702
1
3
4
2
1)
Security Slot
Compatible with the Kensington
®
Secu-
rity Slot specification. Useful for secur-
ing the recorder to a fixed object with a
compatible computer lock.
2)
CompactFlash Slot
Accepts CompactFlash cards with the
label-side up. Compatible with Type I,
Type II, and MicroDrives.
3)
Battery Mount
Accepts Sony
®
InfoLithium L- or M-
Series removable batteries. Also accepts
batteries conforming to this mount. Vari-
ous capacities, from 1500 mAh to 7000
mAh are available.
4)
Battery Release Pin
Push down the pin with a long skinny
object such as a key, screwdriver, or a
pen. With the pin pushed in, slide the L-
or M-Series battery to the right to release
the battery
