Main unit control – SONIQ QV173LTI User Manual
Page 9
9
- 9 -
No.
14
15
16
17
18
19
20
Name
Power Cord
DVD VIDEO OUT
MONITOR/VGA
(PC IN)
Description
Connect to the AC wall outlet.
Connect the PC VGA signal output of your personal
computer
Connect the PC audio output of your personal
computer.
Connect composite Audio/Video output of your
AV device.
Connect to external antenna.
Main Unit Control
Rear Panel
AUDIO Jack (PC IN)
AUDIO/VIDEO IN
Jacks
PHONES jack
T V A n t e n n a C a b l e
Terminal - Coaxial TV
antenna input
