MAIN UNIT CONTROL
Rear Panel
No.
13
14
15
16
17
18
19
Name
Power Cord
DVD VIDEO OUT
Description
Connect to the AC wall outlet.
Connect the PC audio output of your personal
computer.
Connect composite Audio/Video output of your AV
device.
Connect to external antenna.
AUDIO Jack (PC IN)
MONITOR / VGA
(PC IN)
AUDIO/VIDEO IN
Jacks
PHONES jack
TV Antenna Cable
Terminal - Coaxial TV
antenna input
Connect the PC VGA signal output of your personal
computer
