STEP 7—CHECK THE AIR SYSTEM
Once the inflation valves are installed inflate the air helper springs to 70 P.S.I. and check the fittings for air leaks
with an applied solution of soap and water. If a leak is detected at a tubing connection then check to make sure
that the tube is cut as square as possible and that it is pushed completely into the fitting. The tubing can easily be
removed from the fittings by pushing the collar towards the body of the fitting and then pulling out the tube. If a leak
is detected where the brass fitting screws into the spring, remove the tubing (see trouble shooting section of the
operating instruction manual for removal procedure), then screw the brass fitting into the air spring one additional
turn or until the leak stops. Reinstall the tubing and re-inflate the air springs and check for leaks as noted above.
Further information on trouble-shooting can be found in the General Operation Instruction book included with this
kit.
This now completes the installation. Re-attach the postive battery cable and remove the wheel chocks from the
front wheels. Before proceeding, check once again to be sure you have proper clearance around the air springs.
Wtith a load on your vehicle and the air helper springs inflated, you must have at least 1/2” clearance around the air
springs. As a general rule, the Ride-Rite Air Helper Springs will support approximately 32 lbs. of load for each P.S.I.
of inflation pressure (per pair). For example, 50 P.S.I. of inflation pressure will support a load of 1600 lbs. per pair
of air helper springs. FOR BEST RIDE use only enough air pressure in the air helper springs to level the vehicle
when viewed from the side (front to rear). This amount will vary depending on the load, location of load, condition of
existing suspension and personal preference.
NOTE:
Too much air pressure in the air helper springs will result in a firmer ride, while too little air pressure will allow the
air helper spring to bottom out over rough conditions. Too little air pressure will also not provide the improvement in
handling that is possible.
Enclosed with this kit are Ride-Rite Operating Instructions. Please read them for proper and safe operation.
NOTE:
MIN PRESSURE 5 PSI
MAX PRESSURE (LOADED) 100 PSI
