BAIL
CLAMP
(3373)
3/8ʺ-16
FLANGE
NUTS TO
BAIL CLAMP
1/4 - 20 X 1-1/2
HHCS
3/8" - 16
x 4"
CARRIAGE
BOLT
3/8" - 16 x 4"
CARRIAGE
BOLT
LEAF
STACK
BRACKET STRAP
(1163)
1/4 - 20 X 1-1/2
HHCS
NOTE: Both illustrations are of the left, or
driver’s side, of the vehicle. Reverse any
orientations when assembling and installing
the right, or passenger’s, side of the vehicle.
KIT TO FRAME ASSEMBLY
KIT ASSEMBLY
UPPER
BRACKET
(5769)
LOWER
BRACKET
(5768)
1/8 NPT MALE
FITTING (3055)
5/8 - 18 NUT
W/LOCTITE
1/4 - 20 NYLOCK NUT
1/4 FLAT WASHER
2557/2564
FIGURE “A”
