Rite-Ride 2080 - Manual (Page 2)

3/8” -24 NYLON
INSERT LOCK NUT
FRAME
WHEEL
FRON
T
AIR SPRING
ASSEMBLY
3/8” -24 x 1-1/2”
RIBBED NECK BOLT
LEAF STACK
AXLE
SHOCK BRACKET
AXLE
STRAP
3/8” -24
NYLON
INSERT
LOCK NUT
3/8” -16 FLANGED
HEX BOLT
LOWER
BRACKET
UPPER
BRACKET
3/8” -24 x 2-1/2”
RIBBED NECK BOLT
AIR SPRING
ELBOW
FITTING
3/8” -16 FLANGED
HEX NUT
WHEEL
FRON
T
FIGURE “A”
KIT TO FRAME ASSEMBLY
KIT ASSEMBLY
2080
NOTE: Both illustrations are of the
left, or driver’s side, of the vehicle.
Reverse any orientations when
assembling and installing the right,
or passenger, side of the vehicle.
