TABLE OF CONTENTS


Installation Cautions & Warnings…….………………………………………………………..…………………………………...………………2

Control Module / Component Mounting….………………………..………………………………………………………………….…………..3

Wiring……..…………………………………………………………..……………………………………………………………………………….3-7

Power Door Lock Wiring...…………………………………….…………………………………..……………..……..…………………………8-9

Starter Disable Wiring…………………………..…..………………………………………………………………………………………..……..10

System Wiring Diagram………………….………………..………………….…………………………………………………………….………11

CS-2004TW1/2 Antenna Diagram………...…………………………………………………………………………………….………….…...…12

Option Programming……………..……………………………………………………………..…………………………….……..…….……13-15

Programmable Option Reset……………………….....……….…………….……………………………………………….…………………...16

CS-2004TW1/2 & CS-2004DCII Remote Programming…………………..….…..…………………………………………….…....…….16-17

Remote Operation………………………………………,…………………….………………..….……………………………………….……...18

Transceiver/Pager Remote……………………………,…………………….………………..….……………………………………….……...19

Low Battery Warning – LCD Remote……………………………………………………………………………………………………………20

Setting the Clock (2-Way LCD Remote)………………………………………………………………………………………………………..20

LCD Panel Functions Shown..…………………,…………………….………………..….……………………………..……….………….20-21

Operation…………………………………………………,…………………….………………..…………………………………….….……21-24

2 Vehicle Operation…………………………………,…………………….………………..….…………………………..………….……........25

Carjack Operation…………………………………………………………….…………………..……………………….…..…………………..26

INSTALLATION CAUTIONS & WARNINGS

BEFORE BEGINNING, check all vehicle manufacturer cautions and warnings regarding electrical service (AIR
BAGS, ABS BRAKES, AND BATTERY).

TO PREVENT A POSSIBLE DEAD BATTERY remove vehicle dome light fuse while working on the vehicle. MAKE
CERTAIN TO REINSTALL FUSE PRIOR TO TESTING FOR DOOR TRIGGERS.

DO NOT EXCEED MAXIMUM OUTPUT RATINGS! - SERIOUS DAMAGE MAY OCCUR. LIMITS FOR ALARM
FUNCTIONS ARE LISTED WHERE APPLICABLE.
