Revel Gem - Manual (Page 7)

Figure 4. Installing the base
onto the pedestal.
Figure 5. Installing spikes.
INSTALLING STANDS (OPTIONAL)
1. Unpack all stand boxes. Place a pedestal, base, and top plate on
a soft surface (e.g, rug or soft cloth).
2. Using a Phillips screwdriver, install a base to a pedestal with five
long screws, as shown in Figure 4.
3. Thread four spikes about halfway into the base and tighten each
one with a locking ring, as shown in Figure 5.
continued on next page...
REVEL ULTIMA GEM
Owner’s Manual
7
Pedestal
Base
(5) Long Screws
(Start All Screws
Before Tightening)
(4) Spikes
(4) Covers*
(optional for hardwood
or tile floors)
(Optional) Use Covers*
For Hard Floors
(4) Locking
Rings
*NOTE: Apply a small bead of supplied
silicone adhesive into each cover and
fasten onto each spike. Wait 20 minutes
for silicone to set.
