8
Driver Complement
(continued)
3. Woofers
• Two 5-inch (127mm) cones
constructed with Organic Ceramic
Composite cone material
• Die-cast basket to eliminate
coloration from resonances
• True pistonic operation for
increased freedom from coloration
• Two high-grade Neodymium
magnets placed inside the voice
coils for optimal magnetic shielding
• Copper ring inside the motor’s gap
for modulation control and low
distortion
• Integrated aluminum flux-
stabilization ring for modulation
control and low distortion
• 1.5-inch (38mm) voice coils wound
on fiberglass bobbins for low
compression
• Vented center pole for improved heat
dissipation and low compression
CABINET
Reduces cabinet-induced colorations with
0.75-inch (19mm) thick walls and extensive
internal bracing. For even greater sound
enhancement, rounded baffle edges
minimize diffraction and optimize treble
response. Two threaded inserts on the
bottom of the cabinet accommodate spike
footing, which provides adjustable tilt when
the C32 is placed on or above a video
monitor.
The cabinet’s wood veneer finish does not
require routine maintenance. However,
cabinet surfaces that have been marked
with fingerprints, dust, or other dirt can be
cleaned using a soft cloth and a high-
quality furniture polish. If a higher-gloss
finish is desired, a high-quality wax can
also be used.
To clean the cabinet:
1. Apply a high-quality furniture polish
to a soft cloth.
2. Use the cloth to lightly wipe the cabinet
surface.
To clean the grille:
1. Gently vacuum using a soft-bristled
brush vacuum attachment.
CAUTION
To prevent cabinet damage, do not use
a cloth made with steel wool or metal
polish to clean the cabinet.To prevent
possible transducer damage, do not
apply furniture polish directly to the
cabinet.
FILTER NETWORK
Optimize loudspeaker on and off-axis
response with high-order filters at 280Hz
and 2.5kHz, helping to ensure smooth
octave-to-octave balance and timbral
accuracy. Separate woofer, midrange, and
tweeter filter boards prevent mutual
interference between filter network
components, dramatically reducing distortion
over a wide dynamic range. Removable
shorting-straps and gold-plated binding
posts accommodate single-wired, bi-wired,
and bi-amplified connections, while separate
Placement Compensation and High
Frequency Level controls provide precise
balance to compensate for less-than-ideal
listening room acoustics and loudspeaker
placement.
