Ultima Salon2/Studio2
Owner’s Manual
4
ABOUT THE STUDIO2
The Revel Ultima Studio2 is a floorstanding design featuring all
of Revel’s latest technological innovations and enhancements
which offers a designer-friendly elegant appearance and
unparalleled sound quality. A three-way system utilizing two 8-
inch woofers, a 5.25-inch midrange and a 1-inch tweeter, the
Studio2 features the graceful look of the new Ultima2 series. Its
somewhat smaller size makes it ideal where space is limited but
uncompromised performance is required. Their elegant design
even extends to their cast aluminum input and control panels,
which are hidden from view, yet easily accessible.
PRODUCT REGISTRATION
Please register the Salon2/Studio2 within 15 days of purchase. To
do so, register online at the www.revelspeakers.com website or
call Harman Specialty Group Customer Service. Retain the
original, dated sales receipt as proof of warranty coverage.
WHAT’S IN THE BOX
• (1) Salon2 or Studio2 Loudspeaker
• (4) 2.25-inch (57mm) Combination Spikes/Glides
• (4) Locking Rings
• (4) Felt Washers
• (1) Grille
• (1) Salon2/Studio2 Owner’s Manual
• (2) Spare Rear Door Washers
UNPACKING
The Salon2/Studio2 requires special care and handling during
unpacking. Pay particular attention to the precautions that
appear in this section and throughout this owner’s manual.
To unpack the Salon2/Studio2 Loudspeaker you must have at
least two people. The procedure for unpacking the Salon2 and
Studio2 Loudspeakers is similar. Please use the following
instrctions for both loudspeakers. To unpack the loudspeaker
perform the following steps:
1. Place the loudspeaker carton in an upright position, as
indicated by the “This End Up” indications on the carton.
2. Open the flaps as shown in Figure 1, Step 1, on the next
page.
3. Without allowing the flaps to close invert the carton onto a
carpeted area or soft cloth so that the open flaps of the box
are on the bottom. Be careful to keep the loudspeaker within
the box as you are tilting it onto the floor.
4. Lift the box off the loudspeaker and place it aside, Figure 1,
Step2.
5. Carefully lift the loudspeaker into an upright position and
then remove the foam packing strips from the top. Remove
the two center sections of packing foam by carefully sliding it
up, and off the loudspeaker. Use caution to avoid damaging
the transducers while removing the foam packaging.
Warning
Do not attempt to lift or move the Salon2/Studio2 alone.
Proper lifting requires at least two strong people. When
lifting the Salon2/Studio2 keep your back as straight as
possible using the leg muscles to lift. Failure to follow
these procedures may result in personal injuries and/or
loudspeaker damage.
