Adjust the hinge tension with a
Philips head screwdriver.

Kas-I80-1 Kas-I80-2 KAS-48

Part Description Dimensions Weight Holds
Number (Empty)

KAS-I80-2 Image 85 Ship Case (2) 56.5” x 16” x 35” 103lb / 46.4Kg Image 85 (2)

143.5cm x 40.5cm x 89cm

8KAS-I80-1 Image 85 Ship Case (1) 56.5” x 8” x 35” 29lb / 13.1Kg Image 85 (1)

143.5cm x 20.5cm x 89cm

KAS-I40-1 Image 45 Ship Case (1) 56.5” x 9” x 23.5” 27lb / 12.2Kg Image 45 (1)
143.5cm x 23cm x 59.5cm

KAS-I20-1 Image 20 Ship Case (1) 31” x 10” x 23” 20lb / 9Kg Image 20 (1)
78.5cm x 25.5cm x 58.5cm

KAS-48 4ft Lamp Ship Case 52.5” x 10.5” x 11” 15.5lb / 7Kg 4ft Lamps (20)
133cm x 26.5cm x 28cm
