Kino Flo Image 80, 40 & 20 DMX User Manual
Page 12
XLR-515 DMX Cable 5 Pin, 15ft
XLR-525 DMX Cable 5 Pin, 25ft
BRD-I80 Image 80 Barndoors Set of 4
BRD-I40 Image 40 Barndoors Set of 4
BRD-I20 Image 20 Barndoors Set of 4
Side Door
X2
Top and Bottom Door
1. For the Side Doors, align the
hinge bracket tabs with the two
square receptacles on the side
of the fixture.
12
