8
Mounting to Fixture
Mounting To Lamp Harness
It is possible to mount “Harness Only” with the
plastic shell removed. Align the center pin of the
mount to the receptacle hole in the lamp holder
harness.
Rotate the mount clockwise until the locking pin
clicks into place.
To release, pull the pin up and rotate counter
clockwise.
Align center pin with mating plate on fixture.
Rotate in a clockwise direction to secure mounting
plate. Locking pin will snap into place.The yellow
safety wire loop provides an attachment for a
safety chain.
Unlock the mounting plate by pulling up on the
locking pin and rotate mount in a counter clockwise
direction.
A 180° turn loosens the orientation of the mount.
A right turn tightens the mount.
The tension on the lock lever may be adjusted
by pulling the handle away from the mount.
This disengages the handle from the screw
mechanism and allows the lever to be reoriented.
