Fixture Assembly
A) Fixture Shell
B) Lamp Harness
C) Reflector
D) Louver, Black Honeycomb 90°
The Vista Single Fixture is comprised of a removable Fixture Shell,
Lamp Harness, Reflector and Louver. The Louver and Reflector are
held in place with Velcro fasteners. The Harness is secured by a
locking pin mechanism on the Fixture Shell.
A
B
C
D
