Mega double control panel – Kino Flo Mega Single User Manual
Page 9
9
A)
Circular Output Connector: Provides electrical power to the
lamp head with the use of an extension cable.
B)
Fuse: Provides circuit protection. Note: If Fuse is “blown” or “open”,
replace with same type of fuse rating as marked.
C)
Manual Switches: Turns lamps on and off manually.
D)
HO/STD: Set to HO for High Output and Std for Standard light
output.
(Note: The Mega Double ballast is shown for example purposes.)
Mega Double Control Panel
A
B
C D
