7
Other Fixture Mounting Options
Extension Cable
The grommet holes along
the edge of the fixture are
designed to allow the fixture
to be screwed onto set walls.
To insert the cable, position the logo up to align
the key ways on the extension cable with the circular
receptacle on the ballast. Rotate the locking ring
until it clicks into the lock position.
Lamps can operate as far as 75 feet from the ballast.
(3 x 25ft extensions)
A Splitter can be used at the Ballast or on the end
of an Extension Cable to split a Mega Double run
into two Mega Singles. This allows for greater rigging
flexibility.
A Combiner can connect smaller ballasts to a larger
fixture. For example, two Mega Single Ballasts can
be combined to a Mega Double Extension or Fixture.
