Kino Flo Mega Single - Manual (Page 5)

5
Inserting Lamps
Gelling the Fixture
Locking Lamp Connector:
Depress both tabs on lamp connector and apply to lamp pins. Match the Harness
color-codes at each end of the lamp. Push lamps into the fixture’s Lamp Holder Clips.
Note: Mega 4Bank fixture is shown for example purposes only.
Restricting the airflow around the lamps can cause the lamps to operate hotter.
This increased heat will raise the lamp’s color temperature and green spike.
Therefore, it is recommended to clip gels to the doors of the fixture.
Remove louvers. Do Not clip gels to louver. Do Not block the fixture ends in a
manner that restricts airflow.
