Page 3: Recommended sizes

background image

3

Inlet Pressure (psi)

Valve

Size

20 40 60 80 100 120 140 160

(Inches)

4" x 5" Float

5" Dia. Float

3

8

4" Dia. Float and #11 Stem

and

and

6" Dia. Float and #11 Stem

#11 Stem

#11 Stem

4" Dia. Float

4" x 5" Float

5" Dia. Float

8" Dia. Float

1

2

and

and

and

6" Dia. Float and #11 Stem

and

#11 Stem

#11 Stem

#11 Stem

#11.5 Stem

4" Dia. Float

4" x 5" Float

5" Dia. Float

6" Dia. Float

3

4

and

and

and

and

7" Dia. Float and #11.5 Stem

#11 Stem

#11 Stem

#11 Stem

#11.5 Stem

7" Dia. Float

8" Dia. Float

10" Dia. Float

12" Dia. Float

1 and

and

and

and

#11.5 Stem

#12.5 Stem

#12.5 Stem

#12.5 Stem

8" Dia. Float

10" Dia. Float

12" Dia. Float

P16 Float

1

1

4

to 2

and

and

and and

#13 Stem

#13 Stem

#13 Stem

#13 Stem

This chart is used to select the proper float and stem for the selected valve size at a given inlet pressure. Do not exceed the maximum pressure of the selected valve. Example:

Valve inlet -

3

4

”, inlet pressure - 85psi, use a 6” diameter float and a #11.5 stem.

Heavy Duty Float Valves

Features

Pipe-threaded for pipe connections and

straight-pipe threaded for locknut

Machined flange for support against tank wall

All bronze bodies

Serrated arms for quick easy adjustment of water

level (all sizes)

High tensile manganese bronze long and short arms

No jam single lever action

Replaceable seals

Flow Specifications

Size Pressure Flow Pressure Flow

3

8

"

50psi

14 gpm

100psi

21 gpm

1

2

"

50psi

20 gpm

100psi

31 gpm

3

4

"

50psi

40 gpm

100psi

60 gpm

1"

50psi

100 gpm

100psi

150 gpm

1

1

4

" - 2"

50psi

250 gpm

100psi

348 gpm

Item

Qty.

Description

Material

1

1

Body

Bronze

2

1

Plunger

Brass

3

1

Long arm

Bronze

4

1

Short arm

Bronze

5

1

Plunger tip

Buna-N

6

1

Leather ring

7

1

Thumb screw

Brass

8

1

Cotter pin

Stainless Steel

Recommended Sizes

No Jam

Linkage

Machined Flange

High Tensile

Manganese

Bronze Arm Set

Serrated Arms

Pipe/Straight

Thread (NPSM)

All Bronze Body

Cotter Pin

Pivot Assembly

Inlet

Connection

(FNPT)
