Watts LFWP16B User Manual
Lead free, Brass crimpring, Cinchclamp

Lead Free* Brass CrimpRing
™
& CinchClamp
™
Couplings and
Coupling Kits are used for making WaterPEX
®
repairs in the
field, continuing a run as well as transitioning from polybutylene
pipe to WaterPEX
®
tubing. The Lead Free* Brass Couplings
feature Lead Free* construction.
Specifications
System shall be plumbed using Watts WaterPEX
®
cross-linked
polyethylene pipe, and all joints shall be made using Watts
Lead Free* Brass CrimpRing
™
and/or Poly-alloy CrimpRing
™
fittings using either the Watts copper CrimpRing
™
or stainless
steel CinchClamp
™
crimping methods as outlined in the Watts
Installation Guidelines. The couplings shall be constructed using
Lead Free* Brass. Lead Free* Brass couplings shall comply
with state codes and standards, where applicable, requiring
reduced lead content.
Installation Note
Lead Free* Brass Couplings must be installed in accordance
with all Watts installation procedures, including information
provided in installation manual and guidelines.
Approvals
• Manufactured in accordance with American Society for
Testing and Materials (ASTM International) F877 and F1807
• Listed by the NSF International to NSF Standards 14 and 61
for use in potable water systems
• Listed by NSF International to be in compliant to the Uniform
Plumbing Code
• Labeled B137.5 which indicates that it is compliant to the
CSA Standards B137.5
LFWP15
PEX x PEX CrimpRing
™
Coupling
LFWP8S
PEX x PEX CinchClamp
™
Coupling Kit
(Each kit contains 4 CinchClamps
™
and 2 brass couplings)
LFWP16
PEX x PEX CrimpRing
™
Coupling Kit
(Each kit contains 4 copper CrimpRings
™
and 2 brass couplings)
LFWP17
PEX x PB Transition Coupling Kit
(Each kit contains 2 copper CrimpRings
™
and one PB coupling)
Note: Watts WaterPEX Lead Free* CinchClamp
™
fittings
should not be used with wrought copper PEX fittings.
* The wetted surface of this product contacted by consumable water
contains less than one quarter of one percent (0.25%) of lead by weight.
For Residential and Commercial Applications
ES-WP-LFBrassCouplings
Job Name –––––––––––––––––––––––––––––––––––––––––––
Contractor ––––––––––––––––––––––––––––––––––––––––––––
Job Location –––––––––––––––––––––––––––––––––––––––––
Approval –––––––––––––––––––––––––––––––––––––––––––––
Engineer –––––––––––––––––––––––––––––––––––––––––––––
Contractor’s P.O. No. ––––––––––––––––––––––––––––––––––
Approval –––––––––––––––––––––––––––––––––––––––––––––
Representative ––––––––––––––––––––––––––––––––––––––––
LEAD FREE
*
Watts product specifications in U.S. customary units and metric are approximate and are provided for reference only. For precise measurements,
please contact Watts Technical Service. Watts reserves the right to change or modify product design, construction, specifications, or materials with-
out prior notice and without incurring any obligation to make such changes and modifications on Watts products previously or subsequently sold.
Lead Free
*
Brass
CrimpRing
™
&
CinchClamp
™
Couplings
